Installation:

Link to install video (Manual Fold): https://youtu.be/lUpKS3z5lw8

Link to install video (Power Fold, Vehicle Originally Equipped): https://youtu.be/lUpKS3z5lw8

Link to install video (Power Fold, Vehicle NOT Originally Equipped): https://youtu.be/Ozz0YblYg80

Why Choose Boost Auto Parts?

The Claim: Plug & Play

• The Competition: Mirror does not adjust properly when mirror is in flipped position.
• Boost Auto: Mirror adjusts properly in flipped and normal positions without reflash.

The Claim: Proper Fit For 2013+

• The Competition: Mirror does not come with temperature sensor. Check engine light occurs.
• Boost Auto: Temperature sensor pre-installed in the mirror. No check engine light after installation.

The Claim: Forward Light Function

• The Competition: Signal Only
• Boost Auto: Switchback, Signal and Running Light, OR Signal Only

The Claim: Heated Lower Glass

• The Competition: Upper Glass Only
• Boost Auto: Upper & Lower Defrost

The Claim: Instructions

• The Competition: No Instructions
• Boost Auto: Detailed Instructions & Videos

The Claim: Technical Support

• The Competition: No technical support, and customer service often speaks broken English
• Boost Auto: Live & helpful American support. We know these trucks because we own these trucks!

The Claim: Serviceability

• The Competition: No stock of parts
• Boost Auto: A full range of parts stocked in our Illinois warehouse

The Claim: Quality Checks

• The Competition: No quality checks. Imported from Asia & shipped directly to you.
• Boost Auto: 100% quality checked & end of line assembled in USA.

The Claim: Warranty

• The Competition: Claims of extended warranties, but denial of warranty claims or no response when issues arise.
• Boost Auto: 1-year warranty upheld, with real technical support to get the problem fixed the right way the first time.

Frequently Asked Questions:

• How do the forward facing lights work?

  Check out the dynamic pictures found on the Product Details tab for an idea of how the lights will function.

  Signal Only: The lights will only flash with signal. They will not illuminate as running light.

  Signal & Running Light 1.0: The lights will flash as a turn signal. At night when the running lights are activated, the lights will operate at 50% intensity for running light, 100% intensity for turn signal.

  Signal & Running Light 2.0: The lights will flash as a turn signal. At night when the running lights are activated, the lights will operate at 100% intensity for running light, 100% intensity for turn signal.

  Switchback: The lights will flash as an amber turn signal during the day. At night when the running lights are activated, the lights will operate at 100% intensity in WHITE for running light. When the turn signal is activated, the lights will operate at 100% intensity in AMBER in a flashing pattern until the turn signal is de-activated (at which point it will return to a solid white light).

• Are your mirrors plug and play?

  · Power Function: If your truck was originally equipped with power mirrors the power function on our mirrors will work properly. Please note our mirrors do not support curbview assist or memory functions. They will still plug and play, but these features will not integrate properly with our mirrors.

  · Defrost Function: If your truck was originally equipped with rear defrost the defrost function on our mirrors will work properly.

  · Signal Function: If your truck was originally equipped with turn signal the signal on our mirrors will function properly. If your original mirrors were NOT equipped with signal, you will need to have the dealer enable sales code LEB

  · Puddle Function: If your truck was originally equipped with puddle lamp the puddle lamp on our mirrors will function properly. If your original mirrors were NOT equipped with puddle, you will need to have the dealer enable sales code LEC

  · Running Light (If Signal & Running Light or Switchback Option is Selected): You must run one wire to a running light feed (harness included). All wiring internal to the mirror is done; you just need to do the truck side wiring (instructions included). You will need to use a fuse tap to hook this up (a fuse tap is offered for purchase with your mirrors).

  · Power Fold: If your truck was originally equipped with power fold the power fold feature on our mirrors will be plug & play. If your original mirrors were NOT equipped with power fold, a switch must be installed and wires must be ran (all included). You will need to do the truck side wiring (instructions included). You will need to use a fuse tap to hook this up (a fuse tap is offered for purchase with your mirrors).

• Do I need to have the vehicle reflashed after installation?

  If you originally had turn signal you will NOT require a reflash.

  If you did not originally have turn signal, you will need to have the codes LEB & LEC enabled.

  All other mirrors on the market require a flash regardless of whether you had signal or not for the mirror to work properly in the flipped position. Boost Auto Parts designed sensors which cannot be found anywhere else that are internal to the mirror which allow the mirrors to be controlled properly in the flipped position without a reflash.

• Will these mirrors adjust properly when they are flipped up?

  Yes, the mirrors will adjust properly in the up or down position! Boost Auto Parts designed sensors which cannot be found anywhere else that are internal to the mirror which allow the mirrors to be controlled properly in the flipped position without a reflash.

  All other mirrors on the market require a flash regardless of whether you had signal or not for the mirror to work properly in the flipped position.

• What color are the LED's when illuminated?

  Smoked Dotted- Amber at all times

  Clear Dotted- Amber at all times

  Smoked Strip- Amber if signal only or signal & running light, color changing (white running light, amber signal) if switchback

  Clear Strip- Amber if signal only or signal & running light, color changing (white running light, amber signal) if switchback

  The puddle light (which shines down towards the ground when you unlock the truck at night) is white when illuminated.

• Are your mirrors power folding?

  If you select the power fold option they will be equipped with power fold (and a harness is included for ease of install if your original mirrors didn't have power fold).

• If I purchase the Signal & Running light or Switchback option, do I need to purchase the dual function harness as well?

  No, the harness is included in the price and we install it.

• Will I get a check engine light after installing these mirrors?

  No you will not! We install a temperature sensor in all of the mirrors prior to shipping them to you.

• Do I need to install a support bracket?

  Ram does offer a support bracket to support the additional weight of towing mirrors. If you did not originally have towing mirrors, your truck will not be equipped with these brackets.

  Most customers find that our mirrors do not require them, however in order to reduce the amount of vibration on the mirrors some customers do opt to install the support brackets. The support brackets do NOT come with the purchase of the mirrors as most customers don't install them.

  If you wish to purchase them, you can purchase them from your local dealer along with the supplied hardware by asking for OEM #'s 68078242AA 68078243AA 6508709AA x6 6507161AA x6

• What vehicles do these fit?

  2009 Ram 1500

  2010 Ram 1500

  2011 Ram 1500

  2012 Ram 1500

  2013 Ram 1500

  2014 Ram 1500

  2015 Ram 1500

  2016 Ram 1500

  2017 Ram 1500

  2018 Ram 1500

  2019 Ram 1500 (CLASSIC ONLY)

  2020 Ram 1500 (CLASSIC ONLY)

  2021 Ram 1500 (CLASSIC ONLY)

  Please check our catalog for other applications.

Vehicle Fitment:

These mirrors fit a wide range of vehicles including the following:

2009 Ram 1500

2010 Ram 1500

2011 Ram 1500

2012 Ram 1500

2013 Ram 1500

2014 Ram 1500

2015 Ram 1500

2016 Ram 1500

2017 Ram 1500

2018 Ram 1500

2019 Ram 1500 (CLASSIC ONLY)

2020 Ram 1500 (CLASSIC ONLY)

2021 Ram 1500 (CLASSIC ONLY)

For exact fitment please reference the above FAQ. Please check our catalog for other years and models

Cross Reference: These mirrors are similar to the below OE #'s (reference above feature list for exact fitment, or contact us if you have questions).

68230829AB / 68230829AC / 68230829AD / 68285871AA / 68285871AB / 68285871AC / 68285871AD / 68285871AE / 68412883AA ; 68143805AA / 68143805AB / 68143805AC / 68143805AD / 68143805AE ; 68142669AD / 68142669AE / 68142669AF / 68285865AA / 68285865AB / 68285865AC / 68285865AD / 68412787AA ; 55372071AA / 55372071AB / 55372071AC / 55372071AD / 55372071AE / 55372071AF / 55372071AG / 55372071AH / 55372071AI / 55372071AJ / 68080083AD / 55372071AK / 55372071AL / 68230828AB / 68230828AC / 68230828AD / 68285870AA / 68285870AB / 68285870AC / 68412880AA ; 68143804AA / 68143804AB / 68143804AC / 68143804AD / 68143804AE ; 68142668AD / 68142668AE / 68142668AF / 68285864AA / 68285864AB / 68412786AA ; 55372070AA / 55372070AB / 55372070AC / 55372070AD / 55372070AE / 55372070AF / 55372070AG / 55372070AH / 55372070AI / 5372070AJ / 68080082AD / 55372070AK / 55372070AL / 68230831AC / 68230831AD / 68285873AA / 68285873AB / 68285873AC / 68285873AD / 68285873AE / 68230831AB / 68416903AA / 68416903AB / 68416903AC / 68261047AA / 68285875AA / 68285875AB / 68285875AC / 68285875AD / 68285875AE / 68412885AA / 68412885AB / 68412885AC ; 68143807AA / 68143807AB / 68143807AC / 68143807AD / 68143807AE ; 68142673AD / 68142673AE / 68142673AF / 68285867AA / 68285867AB / 68285867AC / 68285867AD / 68412813AA / 68412813AB ; 68033735AF / 68033735AG / 68033735AH / 68033735AI / 68033735AJ / 68080093AD / 68033735AK / 68033735AL / 68230830AC / 68230830AD / 68285872AA / 68285872AB / 68285872AC / 68230830AB / 68416902AA / 68416902AB / 68416902AC ; 68261046AA / 68285874AA / 68285874AB / 68285874AC / 68412884AA / 68412884AB / 68412884AC / 68143806AA / 68143806AB / 68143806AC / 68143806AD / 68143806AE ; 68142672AD / 68142672AE / 68142672AF / 68285866AA / 68285866AB / 68412812AA ; 68033734AE / 68033734AF / 68033734AG / 68033734AH / 68033734AI / 68033734AJ / 68080092AD / 68033734AK / 68033734A
