This wiring kit allows all of the lights to be turned on simultaneously when the high beams are activated on GM vehicles. The kit is extremely easy to install and takes less than 10 minutes following our installation video.
After install your lights will function as follows:
- Low Beams Only- Only Low Beams will be on
- Fog Lights Only- Only Fog Lights will be on
- Low Beams & Fogs- Only Low Beams & Fogs will be on
- High Beams- Low Beams, Fog Lights, & High Beams will all be on (GM by default normally turns off the fogs when in high beam, but this kit solves that)
Links to Install Videos:
Link to video A (2:53): https://www.youtube.com/watch?v=P68xDkI-5AI
Link to video B (3:10): https://www.youtube.com/watch?v=2IR_JjzV80o
Link to video C (2:54): https://www.youtube.com/watch?v=8XHyqx1j6jE
Link to video D (3:28): https://www.youtube.com/watch?v=5diuE0BeAPY
Fitment:
2015-2019 Colorado/Canyon (Video A):
- 2015 Colorado and Canyon (All Models)
- 2016 Colorado and Canyon (All Models)
- 2017 Colorado and Canyon (All Models)
- 2018 Colorado and Canyon (All Models)
- 2019 Colorado and Canyon (All Models)
2007.5-2013 (Video B):
- 2007.5-2013 Silverado & Sierra 1500/2500HD/3500HD
- 2007 - 2014 Tahoe & Suburban
- 2007 - 2014 Yukon & Yukon XL
- 2007-2014 Escalade
- 2007-2013 Avalanche
2014 (2500/3500+) (Video B):
- 2014 Silverado & Sierra 2500HD/3500HD
2014 (1500) (Video C):
- 2014 Silverado & Sierra 1500
2015-2019 (Video C):
- 2015-2018 Silverado & Sierra 1500/2500HD/3500HD
- 2019 Silverado & Sierra 2500HD/3500HD
- 2015-2019 Tahoe & Suburban
- 2015-2019 Yukon & Yukon XL
2019+ New Body (Video D):
- 2019 Silverado & Sierra 1500
- 2020 Silverado & Sierra 1500/2500HD/3500HD
PROUDLY MADE IN THE U.S.A
Please note, some video C vehicles may have a solid brown wire in pin 10 rather than a brown with white stripe. Always reference off of the pin locations, NOT the wire colors. If you have any questions please contact us.
